Is it important to adjust the cylindrical grinder and how to avoid tool problems

2025-04-10

How to avoid the problem of tool misalignment in cylindrical grinding machines?To avoid the problem of tool breakage in cylindrical grinders, we should do the following: firstly, maintain the sharpness of the grinding wheel particles, regularly repair the grinding wheel, and choose suitable materials; Secondly, reducing the grinding allowance and extending the grinding time; The third is to fully pour the coolant. By following these three points, the goal can be achieved.Do operators of cylindrical grinders need to hold certificates to work?It is required to hold a certificate for employment and undergo pre job training. Only by passing the pre job training and obtaining the job documents can one operate the external cylindrical grinder. In the pre job training for its operation, operators are required to have an understanding of the structure and composition of the grinder, know the working principle, basi...

What are the reasons for the crawling of CNC end face cylindrical grinding machines

2025-04-10

What are the reasons for the crawling of CNC end face cylindrical grinding machines?The crawling of CNC end face cylindrical grinding machines is often caused by poor lubrication of the worktable running guide rails. The lubrication is too small, or simply due to the blockage of the lubrication channel, the lubricating oil cannot reach the guide rail at all, which increases the friction between the guide rail pairs and causes the crawling phenomenon of the CNC end face cylindrical grinder. At this point, we only need to open up the lubrication channel or increase the lubrication amount appropriately to solve the problem of workbench crawling. It should be noted that the lubrication amount between the guide rail pairs cannot be adjusted too much, otherwise it will cause drift during the operation of the worktable, which will lead to related quality problems of the ground workpiece.Hydraulic system adjustment...

Why is it said that the stability of a grinder determines its quality

2025-04-10

Why does the stability of a grinder determine its quality?There are many hydraulic transmission reversing methods currently used in grinding machines. Based on the analysis of commonly used hydraulic transmission reversing methods, a simple analysis will be made below. The direction change method and control parameters in the system using a stroke direction change valve have a decisive effect on the direction change impact. Below, we will discuss the direction change impact problem of the grinder from the perspective of direction change method and control strategy.A pull rod is connected to the reversing valve core to use a stroke reversing valve for reversing. Use the travel stop on the workbench to push the pull rod to achieve automatic direction change. When the worktable moves slowly, when the directional valve reaches the middle position, whether the left and right chambers of the hydraulic cylinder ar...

What are the three major factors causing vibration in grinding machines

2025-04-10

There are various reasons for the vibration of grinding machines, and the following are the three main reasons compiled by the editor:1. First, check the horizon. If the level of the foundation screws of the machine tool is not adjusted properly, it will cause resonance of the machine tool. Because sometimes the flatness of the ground in the processing site is not good, it is necessary to adjust the horizontal screws to make the machine reach an uneven height. We need to check whether each screw of the foot is properly installed in the floor mat. Use a spirit level to check if the front, back, left, and right are level, and tighten the screws. 2. If the above actions have been taken but the vibration is still not resolved, we should check whether it is due to the virtual space of the ground floor. If the ground is terrazzo or paved with floor blocks, it is relatively solid. If it is a cement floor, the grou...

Discuss whether the durability of CNC grinding wheel is important and how to judge it

2025-04-10

Is it important to discuss the durability of CNC grinding wheel and how to judge it?CNC grinding machine is a specific type of grinding machine, which is also a website product and keyword. Therefore, it is necessary to have a detailed understanding in order to know what it is and how to use it correctly and reasonably with good results, and thus achieve the utilization of the product.From a relevant perspective, the durability of CNC grinding wheels is very important and cannot be underestimated or treated carelessly, because if the durability of the grinding wheel is lower, frequent grinding wheel dressing work is required, resulting in longer single process working hours and greatly reducing the efficiency of the grinding machine. That's why the above conclusion is reached.How to determine the durability of a grinding wheel can be approached from the following two aspects: firstly, judging from the chang...

Attention beginners! How to sharpen the CNC end face cylindrical grinder

2025-04-10

The compact structure, beautiful appearance, flexible adjustment, and easy operation of CNC end face cylindrical grinding machine are the characteristics that beginners should pay attention to. But what are the specific steps when grinding?Grind the main rear blade surface, while grinding out the main deviation angle and main rear angle; Grind the secondary rake angle and secondary rake angle simultaneously on the blade surface after grinding; Grind the back and simultaneously grind the front corner; Grind each blade surface and tip. The posture and method of the grinding tool are to stand in front of the CNC end face cylindrical grinder to prevent fragments from flying out and injuring people when it breaks. Release the gap between holding the knife with both hands and clamp the waist with both elbows to reduce the vibration during sharpening. When sharpening, the cutting tool should be placed in the middl...

Discuss the methods to solve the problem of warping during the grinding process of CNC cylindrical grinders

2025-04-10

Discuss the methods to solve the problem of warping during the grinding process of CNC cylindrical grinders.CNC cylindrical grinding machines are widely used in machining applications, but warping may occur during the grinding process. To solve this problem, the following methods can be used:1. When grinding the above-mentioned thin sheet workpieces on a CNC cylindrical grinder, an elastic clamping arrangement is selected to complete the positioning and clamping of the thin sheet workpieces in a free state. Place a layer of 0.5mm thick rubber between the workpiece and the magnetic worktable. When the workpiece is subjected to magnetic attraction, the rubber is compressed, the elastic deformation is reduced, and then a flat surface of the workpiece can be ground. Repeatedly grinding several times can achieve the required machining accuracy.2. Use epoxy resin bonding agent to bond the thin sheet workpiece to ...

Data display and zero offset of CNC end face cylindrical grinder

2025-04-10

Data display and zero offset of CNC end face cylindrical grinder.1、 The data of the CNC end face cylindrical grinder shows:If the "handwheel mode" is selected under the "JOG" mode, the system will require confirmation of the X-axis or Z-axis. If not confirmed, the tool holder will still move in the previous direction, which can easily cause the tool holder to move incorrectly and result in cutting situations.2、 Zero offset of CNC end face cylindrical grinder:During the operation of modern CNC systems, people often use a zero offset command from G54~G59 tape machines to set the position of the workpiece zero point in the machine coordinate system for CNC end face cylindrical grinders. When using this method, attention should be paid to whether tool compensation is used and which point is used as the reference point for setting the tool compensation value. If the displacement of the machine tool...

Grinding methods on cylindrical grinders

2025-04-10

Grinding methods on cylindrical grinders.1. Longitudinal grinding method: When grinding the outer circle using the longitudinal grinding method, the high-speed rotation of the grinding wheel is the main motion, and the workpiece undergoes circular feed motion while also undergoing longitudinal reciprocating motion with the worktable, achieving axial feed along the workpiece. The longitudinal grinding method is suitable for grinding larger workpieces and is a commonly used method for single piece and small batch production.2. Horizontal grinding method: When using the horizontal grinding method to grind the outer circle, the width of the grinding wheel is larger than the grinding width of the workpiece, and the workpiece does not need to make longitudinal feed motion. The grinding wheel continuously or intermittently makes transverse feed motion at a slow speed to achieve radial feed of the workpiece until t...

Operating procedures for cylindrical grinding machines

2025-04-10

Operating procedures for cylindrical grinding machines.1. When installing the grinding wheel, the action should be light. After installation, it is necessary to conduct an idle test to observe whether there is any deviation, vibration, or other phenomena. Only after there are no problems can it be used.2. The machine tool should be kept clean and tidy. Before driving, check whether the position of its handle and travel limit block is correct.3. When the grinding wheel approaches the workpiece, hand cranking should be used and the workpiece should be observed for any protrusions or indentations.4. When the grinding wheel has not stopped, the coolant cannot be cleaned, or grinding, replacement, or other work cannot be carried out.5. Flat grinding wheel, its extension should not exceed 25 millimeters, and the grinding wheel blocks should be kept parallel.6. If there are burrs on the workpiece, they should be c...
